Machine
function and packaging parameters
|
Bag type
|
Standing/simple
|
Zipper standing/standing/simple
|
Standing/middle and oblique opening, simple
|
|
Type
of consuming film
|
Different laminated films
|
|
Minimum
bag size
|
90*110 mm
|
90*110 mm
|
90*110 mm
|
|
Maximum
bag size
|
180*250 mm
|
180*250 mm
|
180*250 mm
|
|
Product
volume
|
1000 ml
|
1000 ml
|
1000 ml
|
|
Machine
speed
|
40-60 bags/min
|
40-60 bags/min
|
40-60 bags/min
|
|
No.
of filling stations
|
2
|
2
|
2
|
|
Standard
facilities
|
Product outgoing
conveyor belt, Cold Emboss, No bag – No fill
|
|
Facilities
which can be ordered
|
Aseptic Device , Antistatic , CIP , Anti – Dropping
Filling
|
|
Conditions
|
Necessary power
|
8 kw
|
9 kw
|
9 kw
|
|
Necessary
air
|
300 l/min
|
300 l/min
|
300 l/min
|
|
Ambient
temperature
|
-10°C
to +55℃
|
|
Relative
humidity
|
Maximum 85%
|
|
Electric
data
|
380 W/50 Hz (to be changed based
on the order)
|
|
Machine
specifications
|
Machine
dimensions (length*width*height)
|
1500*1100*6000 mm
|
1500*1100*6000 mm
|
1500*1100*6000 mm
|
|
Machine
weight
|
2000 Kg
|
2100 Kg
|
2100 Kg
|
