Machine
function and packaging parameters
|
Bag type
|
Standing/shaped
|
Standing zipper/standing/shaped
|
Standing/middle and oblique opening/shaped
|
Type
of consuming film
|
Different laminated films
|
Minimum
bag size
|
110*90 mm
|
110*90 mm
|
110*90 mm
|
Maximum
bag size
|
250*140 mm
|
250*140 mm
|
250*140 mm
|
Product
volume
|
600 ml
|
600 ml
|
600 ml
|
Machine
speed
|
90-120 bags/min
|
90-120 bags/min
|
90-120 bags/min
|
No.
of filling stations
|
2
|
2
|
2
|
Standard
facilities
|
Product outgoing
conveyor belt, Cold Emboss, No bag – No fill
|
Facilities
which can be ordered
|
Aseptic Device , Antistatic , CIP , Anti – Dropping
Filling
|
Conditions
|
Necessary power
|
13.5 kw
|
15.5 kw
|
15.5 kw
|
Necessary
air
|
400 l/min
|
400 l/min
|
400 l/min
|
Ambient
temperature
|
-10°C
to +55℃
|
Relative
humidity
|
Maximum 85%
|
Electric
data
|
380 W/50 Hz (to be changed based
on the order)
|
Machine
specifications
|
Machine
dimensions (length*width*height)
|
1500*1210*9220 mm
|
1500*1210*10120 mm
|
1500*1210*10120 m
|
Machine
weight
|
3000 Kg
|
3200 Kg
|
3200 Kg
|
