EXP-210 filling machine with a medium speed and a final volume of 1200 ml for filling C-Pack and Doypack ready standing, zipper standing, oblique opening standing, three and four sides sewn bags
Horizontal continuous fillers (سری EXP-210)
EXP-210
EXP-210Z
Machine function and packaging parameters
Bag type
Standing/simple
Standing/simple/zipper
Type of consuming film
Different laminated films
Minimum bag size
90*110 mm
Maximum bag size
210*300 mm
Product volume
1200 ml
Machine speed
50-60 bags/min
No. of filling stations
2
Standard facilities
Product outgoing conveyor belt, Cold Emboss, No bag – No fill
Facilities which can be ordered
Aseptic Device , Antistatic , CIP , Anti – Dropping Filling
Conditions
Necessary power
4.5 kw
Necessary air
300 l/min
350 l/min
Ambient temperature
-10°C to +55℃
Relative humidity
Maximum 85%
Electric data
380 W/50 Hz (to be changed based on the order)
Machine specifications
Machine dimensions (length*width*height)
1400*980*2950 mm
1400*980*3200 mm
Machine weight
1000 Kg
1100 Kg
It is controlled by engine server. Durable and safe, easy adjustments, suitable for filling powdered products
Piston pump
Suitable for liquid, thin and thick products
These fillers are capable to measure and to fill the products
Suitable for filling fine granules
